Factory Custom High Quality Stainless Steel Z Type Chain Bucket Elevator Conveyor Vertical Z Type Bucket Elevator Lifting Hoisting Conveyor Manufactur

Name: Factory Custom High Quality Stainless Steel Z Type Chain Bucket Elevator Conveyor Vertical Z Type Bucket Elevator Lifting Hoisting Conveyor Manufactur
Brand: WESEW
Price: 2000 USD

Buy cheap Factory Custom High Quality Stainless Steel Z Type Chain Bucket Elevator Conveyor Vertical Z Type Bucket Elevator Lifting Hoisting Conveyor Manufactur product

Brand Name : WESEW

Model Number : W003

Certification : ce

Place of Origin : china

MOQ : 1 set

Price : US$2000~US$50,000/set

Payment Terms : T/T, Western Union

Supply Ability : 100 sets per month

Delivery Time : 20~35 working day

Packaging Details : Wooden Case

Material Feature : Heat Resistant, Fire Resistant

Application : Chemical Industry, Grain Transport, Mining Transport, Power Plant

Core Components : Motor

Dimension(L*W*H) : Customized

Specification : Customized

Structure : Conveyor System

Material : Stainless Steel

Customization : Available Customized Request

Contact Now

Customized factory SUS304 Stainless Steel Vertical Z Type Bucket Elevator Lifting Hoisting Conveyor Manufacturer for Building Material Shops, Machinery Repair Shops, Manufacturing Plant

Bucket Elevator
As one kind of widely used conveyor,bucket elevator can elevate materials fromlow position to high position with highefficiency. For many industries, such ascement, coal, gypsum, limestone, dry clayand others, bucket elevator is always onemust equipment for vertically lifting. lt canbe also used in food, chemical industriesfor conveying of bulk solids and granularmaterials.lt is one very stable machinewith simple structure.

Machine frame	Good quality 304 stainless steel or carbon steel
Bucket material	Food grade ABS or PP plastic or 304 stainless steel
Bucket size	1.8L or 2L or 4L or 6L
Speed	Controlled by Delta inverter, adjustable
Max speed	90 buckets/min
Working capacity	3-12M3/H
Lifting height	1.5m standard height or Custimized
Chains	Good quality 304 stainless steel or carbon steel
Outlets	1/2/3 or others
Voltage	110V/220V single phase or 380V 3phase, 50HZ/60HZ
Power	750W

Z-type hopper elevator has modified plastic hopper, carbon steel hopper, stainless steel hopper options.

Features:

1. It can be horizontal and vertical combination transmission, horizontal can be 1.2-40 meters in length, vertical height can be 1.5-30 meters, lifting height up to 100 meters
2. The whole process of feeding, conveying and unloading has no damage to the material itself, which can effectively reduce the scrap rate
3. It can be single point or multi-point automatic feeding, unloading, suitable for a row of several silo feed
4. It the lifting hopper is made of high-strength plastic casting mold, with beautiful appearance, not easy to deformation, high temperature resistance, corrosion resistance
5. The overall design of high integration, high material lifting rate, can be matched with vibration feeder, to achieve system
linkage, fully closed design to respond to health requirements
